| Executing Standards |
IEC60079-0, IEC60079-1, IEC60079-31
EN60079-0, EN60079-1, EN60079-31
|
| Certificate No. |
IECEx EUT 18.0032X EPT 19 ATEX 3224X |
ЕАЭС RU C-CN.АЖ58.В .00179/20 |
| Ex Marking |
Ex db IIC T5/T4 Gb II 2 G Ex db IIC T5/T4 Gb
Ex tb lllC T95°C/T130°C Db II 2 D Ex tb IllC T95°C/T130°C Db
|
1Ex db IIC T5/T4 Gb X
Ex tb IIIC T95℃/T130℃ Db X
|
| Enclosure Material |
Aluminum alloy, powder coated surface RAL7035 |
| Rated Voltage |
Max. 600V AC |
| Rated Current |
Max. 50A |
| IP Rating |
IP66 |
| Ambient Temperature |
T5/T95°C: -55°C~ +40°C, T4/T130°C: -55°C~ +55°C |
| Recommend No. |
2.5sqmm: 8pcs |
| of Internal Terminals |
4sqmm: 8pcs |
